Pamban Bridge — India’s First Vertical Lift Railway Sea Bridge to be Ready Soon. Here’s All You Need to Know About the

The Great Pamban Bridge attracts thousands of tourists from all over the world.

Rameshwaram: India is soon set to get its first vertical lift railway sea bridge and it will be a classic example of Indian Railways’ engineering marvel. Yes, we are speaking of the newly proposed Pamban Bridge which is celebrated as one of the most iconic structures built in the erstwhile era. The Great Pamban Bridge attracts thousands of tourists from all over the world. Offering a visual feast to the onlookers, the Scherzer rolling spans beautifully expand and allow cruisers and ships to pass through. The bridge transports scores of pilgrims visiting the famed Ramanathaswamy Temple.

Here’s All You Need to Know About India’s First Vertical Lift Railway Sea Bridge

• The new bridge will have 100 spans of 18.3 m and one navigational span of 63 m.
• It will be 3.0 metres higher than the existing bridge with navigational air clearance of 22.0 metres above sea level.
• The great Pamban cantilever bridge connects the town of Mandapam in mainland India with Pamban Island, and Rameswaram.
• The estimated cost of the new bridge is Rs 250 crore.

Speaking to news agency ANI, the General Manager of Southern Railway said, “The old Pamban bridge was commissioned on February 24, 1914. So, almost 108 years passed, and now the time has come to move forward with new technologies. The estimated cost of the new bridge is Rs 250 crore and the target is to complete it this year only.”

Giving information about this bridge, the Divisional Engineer and Incharge of Pamban Bridge, Hridayesh Kumar said, “The existing bridge structure has a total length of 2,058 metres comprising 146 spans of steel girders. There are 145 spans of 12.20 m and one navigational span of 61.0 m. The navigational span is also known as Scherzer rolling lift span after the name of railroad engineer William Scherzer who invented it.”

“The vertical clearance of only 1.5 m is available between the high tide level and the bottom of the girder resulting in the splashing of seawater on the girders. In comparison, the new bridge will have 100 spans of 18.3 m and one navigational span of 63 m. It will be 3.0 m higher than the existing bridge with navigational air clearance of 22.0m above sea level,” he further added.

Mentioning the technology for the operation of the new bridge for ships movement, Kumar said, “Because of vertical lift, the full horizontal width of 63 m will be available for navigation. Also, the entire bridge including the navigational span will be designed keeping in mind the Railways plan of electrification and maintaining the speed of the trains at 80 km per hour.”

“In comparison to existing manual operation and control, the new bridge will have electro-mechanical controlled systems which will be interlocked with train control systems. Due to the heavy flow of water, it is also proposed to deploy cutting-edge technologies like stainless steel reinforcement, composite sleepers, and a long-life painting system in the construction of the new bridge,” Kumar added.
